Automatic Servo-Based Vial Filling & Rubber Stoppering

The incoming dry vial are fed through the unscrambler and suitably guided on the moving delrin slat conveyor belt at the required speed of the correct placement below filling unit.

The Filling unit consists of filling Head, Syringes & Nozzles which are used for liquid filling. A star wheel is provided which holds the vial during filling operation. Syringes are mounted on eccentric block and driving through bottom main gear box. Volume can be either increased or decreased by increasing or decreasing stroke length of piston as per filling size. Liquid will reach to filling nozzles through silicon transparent pipe. Nozzle will be having up and down movement with help of cam mechanism and it will come down when vial will be hold by starwheel for filling operation and starts filling when it starts to move up and after completion of filling operation, star wheel delivers four vials together on conveyor for rubber stoppering operation.
